For 25 mm Spring Columns ( 1 inch )
25mm ID New Spring Column Subassemblies
𓂃 AS2002-025A03 Spring Kit for 25mm ID Spring Columns, 2000psi
☂ AS2002-025A04 Spring Kit for 25mm ID Spring Columns, 900psi
⛄ AS2002-025A05 Spring Kit for 25mm ID Spring Columns, 400psi
꧒ AS2002-025013 Guide Tube for 25mm Spring Columns
🃏 AS2002-025A06 1/16" OD, 0.020" ID connecting tube and fittings for use with 25mm ID Spring Column
𓃲 AS2002-025A07 1/16" OD, 0.040" ID connecting tube and fittings for use with 25mm ID Spring Column
🧜 AS2002-025000 Threaded Spacer for 25mm ID, 40cm L Spring Columns
⛦ AS2002-025001 Threaded Spacer for 25mm ID, 70cm L Spring Columns
༺ AS2002-025002 Threaded Flange for 25mm ID Spring Columns
🦩 AS2002-025003 Packing Spacer for 25mm ID Spring Columns
AS2002-025004 Unpacking Spacer for 25mm x 40cm SC / ASFC hardware
☂ AS2002-025005 Unpacking Spacer for 25mm x 70cm SC / ASFC hardware
25mm ID Spring Column WordStrment Parts
ꦦ AF0000-C02501 1um Bed Support Frit for 25mm ID Spring Column Outlet
﷽ AF0000-C02502 2um Bed Support Frit for 25mm ID Spring Column Outlet
ꦛ AF0000-C02503 5um Bed Support Frit for 25mm ID Spring Column Outlet
🌳 AF0000-D02501 60um Frit - Outlet Disperser 25mm Column
ꦅ AH0000-R025A3 Inner O-Ring for 25mm i.d.SC outlet
♒ AH0000-R025A4 Outer O-Ring for 25mm i.d. SC outlet
ꦏ AS2002-C02501 1um DD piston frit for 25 mm SC
൲ AS2002-C02503 2um DD piston frit for 25 mm SC
🔴 AS2002-C02503 5um DD piston frit for 25 mm SC
༺ AS2002-025011 Piston O-Ring 25mm SC
♏ AS2002-025007 Piston for 25mm ID Spring Columns
🃏 AS2002-025010 PTFE Sleeve for 25mm SC
♌ AS2002-025A08 WordStrment bolts, nuts, and washers for non-water jacketed 25mm ID Spring Columns
ꦯ AS2002-025A11 WordStrment bolts, nuts, and washers for water jacketed 25mm ID Spring Columns
For 50 mm Spring Columns ( 2 inch )
50mm ID Spring Column Subassemblies
൩ AS2002-050A03 Spring Kit SS (18-8) for 50mm ID Spring Columns, 32 pcs, 2000psi
🐻 AS2002-050A06 Spring Kit (Steal) for 50mm ID Spring Columns, 40 pcs, 2000psi
AS2002-050013 Guide Tube for 50mm Spring Columns
🍨 AS2002-050A07 1/16" OD, 0.040" ID connecting tube and fittings for use with 50mm ID Spring Column
🍒 AF2002-050A08 1/8" OD, 0.060" ID connecting tube and fitting for use with 50mm ID Spring Column
ꦫ AF2002-050A09 1/8" OD, 0.085" ID connecting tube and fitting for use with 50mm ID Spring Column
꧟ AS2002-050000 Threaded Spacer for 50mm ID Spring Columns (20 cm long)
ౠ AS2002-050001 Threaded Spacer for 50mm ID, 70cm L SC, replaced by ( 210357 + 2103159 )
🅘 AS2002-050002 Threaded Flange for 50mm ID Spring Columns
🧸 AS2002-650002 Threaded Flange for 50mm ID SC – old 6 bolt design
🔯 AS2002-050003 Packing Spacer for 50mm ID Spring Columns
AS2002-050004 Unpacking Spacer for 50mm x 40cm SC / ASFC hardware
🍎 AS2002-050005 Unpacking Spacer for 50mm x 70cm SC / ASFC hardware
50mm ID Spring Column WordStrment Parts
♍ AF0000-B05001 1um Bed Support Frit for 50mm ID Spring Column Outlet
⛦ AF0000-B05002 2um Bed Support Frit for 50mm ID Spring Column Outlet
♕ AF0000-B05003 5um Bed Support Frit for 50mm ID Spring Column Outlet
ꦜ AF0000-D05001 60um Frit - Outlet Disperser 50mm Column
ꦺ AH0000-R0050A3 Inner O-Ring for 50mm i.d.SC Outlet
🎃 AH0000-R0050A3 Outer O-Ring for 50mm i.d. SC Outlet
🗹 AS2002-C05001 1um DD Piston Frit 50 mm ID SC
ꦕ AS2002-C05002 2um DD Piston Frit 50 mm ID SC
﷽ AS2002-C05003 5um DD Piston Frit 50 mm ID SC
♊ AS2002-050007 Piston for 50mm ID Spring Columns
🅺 AS2002-050010 PTFE Sleeve for 50mm SC
🔯 AS2002-050011 Piston O-Ring 50mm SC
ܫ AS2002-050A10 WordStrment bolts, nuts, and washers for plain jacketed 50mm ID SC
AS2002-050A13 WordStrment bolts, nuts, and washers for water jacketed 50mm ID SC
ܫ AS2002-650A10 WordStrment bolts, nuts, and washers for plain jacketed 50mm ID SC
🃏 AS2002-650A13 WordStrment bolts, nuts, and washers for water jacketed 50mm ID SC
For 101mm Spring Columns ( 4 inch )
101mm ID Spring Column WordStrment Parts
🐠 AS4004-101000 Threaded Packing Spacer 101mm x 40cm SC
🔯 AS4004-101001 Threaded Packing Spacer 101mm x 70cm SC
🍌 AS4004-101002 Threaded Locking Ring for 101mm ID SC
🎶 AS4004-101003 Packing Spacer for 101mm SC
🦄 AS4004-101007 Piston 101mm SC
🐟 AS4CE4-101008 CE-Top Restraint for 101mm ID SC
💧 AS4CE4-101009 CE-Bottom Restraint for 101mm ID SC
ꦆ AS4004-101010 Piston Top for 101mm ID SC
ꦜ AS4004-101011 O-ring for 101 cm SC
💙 AS4004-101012 Heat Shrink PTFE for 101mm SC (1 piece)
ᩚᩚᩚᩚᩚᩚᩚᩚᩚ𒀱ᩚᩚᩚ AS4004-101013 Guide Tube for 101mm ID Spring Kit
൩ AS4004-101016 2um DD Piston Frit 101mm SC
🐈 AS4004-101015 5um DD Piston Frit 101mm SC
AS4004-101005 Unpacking Spacer for 101mm x 40cm / 70cm SC hardware
📖 AS4004-101020 PTFE Backup O-Ring, 101 SC
